Lathe - cycle controled
WEILER E 35
- Stock number:
- 1087-0303088
- Year / Condition:
- 2001
- Control unit:
- cyclecontrolled (Siemens/Weiler D2)
- Country of origin:
- Germany
- Freight basis:
- EXW, free on truck
- Item location:
- Leipzig 1
- Delivery time:
- by arrangement
Picture / documents / videos
Technical specs
Details
- turning diameter over bed:
- 410 mm
- turning dia. over face-slide:
- 200 mm
- turning length:
- 950 mm
- bed width:
- 330 mm
- turning diameter over support:
- 410 mm
- face slide travel:
- 630 mm
- centre height:
- 200 mm
- control:
- Siemens/Weiler D2
- milling spindle dia. in forward position:
- 90 mm
- spindle bore:
- 54 mm
- range of revolution per miute:
- 1 - 3000 U/min
- feed speed:
- 0 - 20 mm/U
- rapid travel - longitudinal/face:
- 10/5 m/min
- tailstock taper MT:
- 4
- diameter of quill:
- 65 mm
- quill stroke:
- 120 mm
- weight of the machine ca.:
- 2,1 t
- dimension machine approx.LxWxH:
- 2,3 x 1,4 x 1,7 m
Description
The E35 is neither a purely manual machine nor a classic CNC, but a hybrid:
Work like on a conventional lathe
Automatic cycles at the push of a button
No complex programming required
Extremely fast for single parts & small batch production
Also suitable for operators without CNC knowledge
Weiler describes it as follows:
Simple parts like conventional machining
Complex parts like CNC, but easier
