Machining centre
ZIMMERMANN FZ 33
- Stock number:
- 1048-7-47152
- Year / Condition:
- 2016
- Control unit:
- CNC (HEIDENHAIN iTNC 530)
- Country of origin:
- Freight basis:
- EXW 'as is where is'
- Item location:
- Delivery time:
- immediate
Picture / documents / videos
Technical specs
Details
- Controls:
- HEIDENHAIN iTNC 530
- BASIC DESIGN:
- .
- - basic design : gantry type :
- .
- WORKING RANGE -MILLING-:
- .
- - x-axis traverse:
- 2500 mm
- - y-axis traverse:
- 3000 mm
- - z-axis traverse:
- 1250 mm
- - Number of controlled axes:
- 5
- TABLE:
- .
- - clamping surface (left-right):
- 3250 mm
- - clamping surface (front-back):
- 2500 mm
- WORKING SPINDLE / HEAD:
- .
- - spindle type : Fork head :
- .
- - tilting range:
- 220 °
- - - mode of operation : automatic :
- .
- - tilting range (2nd axis):
- 300 °
- - - mode of operation : automatic :
- .
- - spindle revolutions (max):
- 22000 /min
- - taper fixture : HSK A63 :
- .
- - drive power (max):
- 60 kW
- TOOL MAGAZINE:
- .
- - number of positions:
- 50
- ATTACHMENTS:
- .
- - high pressure cooling syst. (through spindle) : yes :
- .
- - chip conveyor : yes :
- .
Description
Technical description :
FORK TYPE Milling head VH30, swiveling axis A +/-110°, turning axis C +/- 300° , High frequency spindle Siemens-Weiss with 22.000 rpm, Spindle power 60 kW, 50 fold tool changer, Taper HSK 63, Vibration sensor, Temperature sensor, dynamic collition protection, Infrared measuring Renishaw RMP 60, Toolsetter BLUM Control NT-Micro, Milling head measuring KinematOpt,Chip conveyor, coolant unit Innercooling 40 bar, Filter unit, Cooling unit,
