Portal - Machining Center

Details

x-axis:

4000 mm

y-axis:

3000 mm

z-axis:

1500 mm

total power requirement:

30 kW

weight of the machine ca.:

117 t

dimensions of the machine ca.:

9,5 x 6,7 x 6,2 m

Passage height:

1550 mm

Passage width:

2500 mm

table width:

2000 mm

table length:

3000 mm

max. table load:

12.000 kg

tool taper:

HSK-A100

max. tool weight:

30 kg

max. tool diameter:

250 mm

tool length - max.:

500 mm

bore spindle turning speed range:

5-6.000 U/min

max. torque on milling spindle:

800

Description

Machine weight: 93 tons
Total weight: 117 tons
