Circular saw

Details

saw blade diameter:

Ø 400 - 450 mm

hole of sawblade:

Ø 50 mm

revolution per minute:

Spindel: 6 / 12 / 24 / 48 (2 step) U/min

revolution per minute:

Motor: 1400 / 2800 U/min

cutting range 90 degrees: round:

Ø 150 mm

cutting range 90 degrees: square:

140 x 140 mm

cutting range 90 degrees: flat:

400x30 / 345x70 / 300x95 mm

table-size:

Ø 700 mm

table rotating:

360 °

air-pressure connection:

6 - 8 bar

total power requirement:

3,6 kW

weight of the machine approx.:

1900 kg

dimensions of machine:

T:1,5 x B:1,0 x H:2,35 m

Description

CIRCULAR SAW SEMI-AUTOMATIC - PROFILE CIRCULAR SAW MACHINE - UNDERFLOOR SAW

Profile circular saw with two-hand control
for sawing materials: steel as solid material, pipes and profiles, taking into account the cutting area.
Cutting speed depends on the material to be sawn
Mitre: 30° - 45° - 90°
Operating pressure/clamping pressure: 50bar / 30bar adjustable
Hydraulic pump 2.2 kW power output
Coolant system with pump
Operation via control panel / two-hand operation
