hydraulic Workshop Press
Rodcraft WP30P
- Stock number:
- 1087-0700037
- Year / Condition:
- 2022 / New
- Control unit:
- conventional
- Country of origin:
- Germany
- Freight basis:
- EXW, free on truck unpacked
- Item location:
- Leipzig 1
- Delivery time:
- immediately
Picture / documents / videos
Technical specs
Details
- Pressure:
- 30 t
- stroke:
- 142,5 mm
- table surface area:
- 500 x180 mm
- passage opening in table:
- 500 x160 mm
- distance between columns:
- 1000 mm
- daylight dimension : table/slide up:
- 120 - 1020 mm
- machine weight approx.:
- 176 kg
- dimension machine approx.LxWxH:
- T: 0,8 x 0,8 x 1,8 m
Description
Simple hydraulic double column press - special construction welded from 20mm sheet steel.
Table support with prism 260 x 205mm
Lower beam installation height max./min.: 1031 / 151mm
Table height above floor max./min.: 1290 / 300mm
Vertical lower beam, adjustable, manual, 10 steps, 100mm distance between steps
Plunger cheek Lifting cylinder Ø 63mm with plunger holder Trunnion bore Ø 25 x 25mm
