Details

x-travel

980 mm

y-travel

340 mm

z-travel

440 mm

spindle taper ISO

SK 50 (vertikal)

distance table/horizontal spindle

max. 440 mm

cross rail adjustment - horizontal

700 mm

range of revolution per miute

32 - 1600 / 18 step U/min

spindle taper

SK 50 (horizontal)

quill travel

 mm

swival range +/-

Fräskopf: bei 90° = 360° und bei 45° = 360° Grad

clamping surface area

1120 x 320 mm

table swivable approx.

45° rechts/links

feed:

 mm/min

rapid traverse



total power requirement

10 kW

machine weight approx.

 kg

dimension machine approx.LxWxH

2,4 x 2,1 x 1,8 m

Control unit

conventional

Operating manual

1
