Details

x-travel

630 mm

y-travel

600 mm

z-travel

670 mm

control

Fanuc MSX 501 Mapps

turning speeds

14000 1/min

spindle drive

22 kW

Number of tool station

60 BT 40

max. tool length

400 mm

max. tool weight

12 kg

tool changing time

1,3 sec

numbers of pallets

2

Pallet dimension

500x500 mm

working diameter

730 mm

workpiece height

900 mm

table load

0,5 t

table - indexing

1 °

rapid travel x/y/z

50 m/min

total power requirement

50 kVA

weight of the machine ca.

14 t

Control unit

CNC

Maker of control unit

Fanuc MSG 501

Accerories

Chip conveyor



Coolant through spindle 50 bar with filter
