Hydraulic C-Frame (Drawing) Press

Details

pressure:

100 t

throat:

510 mm

stroke:

600 mm

Distance table/ram, stroke up:

1000 mm

Table surface area:

1025 x 650 mm

Die cushion pressure in table:

25 t

Die cushion stroke in table:

150 mm

Die cushion area in table:

600 x 400 mm

Table height above floor:

970 mm

Ram surface:

1025 x 650 mm

Speed down:

350 mm/s

Speed up:

330 mm/s

Working speed:

30 - 43 mm/s

Oil volume:

540 l

Power capacity:

48,0 kW

Weight:

12,0 t

Dimensions (WxDxH):

1,2 x 2,7 x 3,9 m

Additional information

die cushion in table
