Profilbiegemaschine

Details

Winkeleisen/Schenkellänge:

80,80,8 mm

Doppel-T-Eisen über x-Achse:

80,80,8 mm

Beschreibung

Bending centre PBT INDUMASCH

-Make : indumasch PBT Swiss made
-Typ : PBT 25 PC200
-Mach.No: 370
-Age : 2003

-Capacity X axis : 27 t
-Number driven roll : 3 x
-Working Speed : 1 - 24 M/min.
-Torq moment : 1.600 Nm

-Shaft Ø: 105 mm
-Stroke : 265 mm
-Max. roll height : 300 mm

-Hydraulic power X axis: 3,0 kW
-Power all 3 driven rolls: 1,1 kW

-PC 200 Touchscreen CNC
interpolation possible & Electr. radius measuring!

-Dimensions
-Length: 1.480
-Width: 1.200
-Height: 1.360
-Weight: 1.100 Kg

-Ø 60 x Ø 1.000
-T 80 (80 / 8) x Ø 1.000
-iPE 120 x Ø 1.000
-HEB 140 x Ø 2.500
-Tube Ø 114 x Ø 2.000

Please Note: The above information has been obtained to the best of our ability and belief from, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
