Presses - Eccentric Press - Double Column - SCHULER P2ESs 125

Eccentric Press - Double Column

SCHULER P2ESs 125

Stock number:
1087-0700224
Year / Condition:
1964 / as is
Control unit:
conventional
Country of origin:
Germany
Freight basis:
EXW, free on truck
Item location:
Leipzig 2
Delivery time:
on request

Picture / documents / videos

Technical specs

Details

pressure:
125 t
stroke:
28 mm
number of strokes:
56-225 Hub / Min
distance between columns:
1000 mm
ram adjustment:
60 mm
distance table/ram:
376 mm
Table dimensions:
B.950xT:720 mm
passage opening in table:
400x130 mm
height over floor:
1120 mm
ram surface area:
920x540 mm
mortise hole in ram:
Dm 65 x 120 mm
column travel -side:
250 mm
total power requirement:
30 kW
weight of the machine ca.:
15,5 t
dimensions of machine:
3,1x1,34x3,6 m
dimensions electric cabinet LxWxH:
0,64x0,22x1,2 m

Description

This press is high-performance press for mass production /series production.
- Contains left side a material feed via automatic feed (mechanic) and right side a waste cutter. Feed = 0-200mm, roll width =250mm

Partial documentation as a copy available.

Machine is not functional and is on sale as is!
