Chuck
WMW NILES DH B/8 - 250x3
- Stock number:
- 1087-1106030
- Year / Condition:
- - / Used
- Control unit:
- other
- Country of origin:
- Germany
- Freight basis:
- EXW, free on truck unpacked
- Item location:
- Leipzig 1
- Delivery time:
- immediately
Picture / documents / videos
Technical specs
Details
- diameter:
- 250 mm
- passage:
- 80 mm
- width:
- 80 mm
- revolution per minute:
- 2400 U/min
- dimensions:
- Ø 250 x B: 180 mm
Description
incl. 3 clamping jaws mounted, max. clamping range outside: Ø 60 - 188 mm and max. clamping range inside: Ø 17 - 192 mm
with base plate Ø 303 x 48 mm; outer pitch circle Ø 280 mm with 4x M16 holes; inner pitch circle Ø 134 mm with 4x M12 holes; T-slot 3x lengthwise and 3x crosswise, T-slot spacing = 64 mm
Flange = Ø 248 x 13 mm
Accessories:
with chuck key
1 set of soft jaws
