Details

turning diameter

190 / 310 mm

turning length

255/ 755 mm

control

Fanuc 18i - TB

Travel x/z turret 1

307 / 300 mm

Travel y Turret 1

± 30 mm

Travel x/z turret 2

390 / 605 mm

c-axis

Sp. 1 / 2

Spindle 1 RPM

5000 1/min

Spindle 1 Power

11 kW

Spindle 1 max. bar diameter

51 mm

Spindle 2 RPM

5000 1/min

Spindle 2 power

7,5 kW

Turret No.1 stations / rotary tools

12/12

Turret 1 tool RPM

6000 1/min

Turret 1 power rotary tools

3,2 kW

Turret No.2 stations / rotary tools

12/12

Turret 2 tool RPM

6000 1/min

Turret 2 power rotary tools

3,2 kW

total power requirement

 kW

weight of the machine ca.

9,5 t

dimensions of the machine ca.

3,9 x 2,33 m

Pressure of coolant

5/15 bar

chuck diameter

160 mm

Control unit

CNC

Maker of control unit

Fanuc 18i - TB

Accerories

Parts catcher



Chip conveyor right discharge
