Table Type Boring and Milling Machine
WOTAN Rapid 4A R/20
- Stock number:
- 1034-04252
- Year / Condition:
- 1982/2004
- Control unit:
- CNC (SIEMENS 840 D)
- Country of origin:
- Germany
- Freight basis:
- ex site
- Item location:
- ex site
- Delivery time:
- immediately
Picture / documents / videos
Technical specs
Details
- spindle diameter:
- 150 mm
- x-travel:
- 3000 mm
- y-travel:
- 2000 mm
- spindle stroke:
- 700 mm
- dimension of the ram:
- 340 x 340 mm
- ram stroke:
- 700
- column travel:
- 1500 mm
- spindle taper ISO:
- 50
- bore spindle turning speed range:
- 3,2 - 1600 U/min
- table surface area:
- 2000 x 2500 mm
- max. table load:
- 25000 kg
- rapid speed:
- 5 / 10 m/min
- feed speeds:
- 1 - 5000 mm/min
- total power requirement:
- 100 kW
- weight of the machine ca.:
- 57 t
- dimensions of the machine ca.:
- 8,4 x 6,8 x 5,9 m
Description
with CNC SIEMENS 840 D
full B-axis
aerostatic guideways
facing head ( 3,2 - 140 rpm )
angular milling head 1000 Nm
coolant attahcmnet with internal cooling supply
